Hobbywing QuicRun WP10BL60 brushless controller 60A for 1:10
Hobbywing QuicRun WP10BL60 brushless controller 60A for 1:10
Characteristics
Water & Dustproof for use in any weather
(Note: Remove the fan with water before use, Clean and dry the controller immediately after use to avoid damage.)
External programming connection for easy programming via the "Program Card".
Proportional brake with adjustable maximum braking force and automatic brake
9 different acceleration programs from "soft" to very "aggressive" can be selected depending on the model and track.
Miscellaneous protection functions:
Battery low voltage protection
Thermal overheat protection
Throttle signal loss protection
Easy programming via a "set" button on the controller
Compatible with the optional "LED Program Card" for even easier programming anytime, anywhere.
Specs
constant / Short term load: 60A/360A
Internal resistance: 0.001 ohms
Motor Type Support: Sensorless Brushless motors
Application: 1/10 On-road/Off-road/Buggy/Monster
engine limit
For 2S Lipo or 6 cell NiMH
On-road: 3656 size or smaller motors with KV < 6000
Off-road/Buggy/Monster: 3656 size motors or smaller with KV < 4000
For 3S Lipo or 9 cell NiMH
On-road: 3656 size or smaller motors with KV < 4000
Off-road/Buggy/Monster: 3656 size or smaller motors with KV < 3000
Batteries:
4-9 cells NiMH
2-3S LiPo
BEC output: 6V / 3A (switch mode)
Dimensions (LxWxH): 48.5 x 38 x 32mm
Weight: 90g
External programming port: Yes
Fan Working Voltage: Directly from battery without regulation
