JP Hobby Multifunction Landing Gears and Doors Sequencer V1/V2 for ER-05/08/10/120/150/200/280
P Hobby Multifunction Landing Gears and Doors Sequencer V1/V2 for ER-05/08/10/120/150/200/280
Description
This new JP Hobby electronic module is used to control the animation sequences of retractable landing gear as well as doors. It can also be used with other enclosures equipped with integrated end of limit switches.

The functions of the JP Hobby module are multiple:
Automatic detection of the supply voltage
Adjusting the supply voltage of the servos actuating the gear doors
Adjusting the direction of rotation of the servos actuating the gear doors
Mode selection:

- 1: Opened gear doors when the landing gear is out
- 2: Closed gear doors when the landing gear is out

Specifications
Dimensions: 63x42x16mm
Voltage range: 7.4-8.4V
Weight: 34.7g
How to use it
To change the direction of the Door Servo:

Long press the "MODE" key
A or B will flash.
press + or - to change the direction.
To change the -100% Servo stroke:

Long press the "MODE" key
A or B will flash.
Press "MODE" once
A and B will flash.
press + and - to increase or decrease stroke
To change Servo stroke +100%:

Long press the "MODE" key
A or B will flash.
Press twice on "MODE"
C and D will flash.
press + and - to increase or decrease stroke
To change the "MODE":

Long press the "MODE" key
A or B will flash.
Press "MODE" 3 times
C or D will flash.
press + for "MODE 1" or - "MODE 2"
